A Small Cube That Sends 1,440 Lumens Down a Narrow Lane

Bolt this cube anywhere you already have a flat surface: a bumper face, a roof rack crossbar, a trailer tongue, a UTV cage. The tight 8-degree spot beam ignores everything at your feet and pushes light out ahead, which is what you want when you are picking a line on a two-track or spotting a gate at the far end of a field.

Four 4-watt high-intensity LED chips deliver 1,440 lumens on 16 watts and a 1.3 amp draw, and the 8-degree optic spends every one of those lumens on distance. It is the tennis player going down the line instead of hitting cross-court: less margin, far more reward when the aim is right. Surface mounting means no cutting, no panel work, just brackets and two bolts.

Key Features

• ✓ 8-degree spot beam built purely for downrange distance
• ✓ 1,440 lumens on 16 watts and only 1.3 amps of draw
• ✓ Universal surface mount for bumpers, roof racks, trailers and UTVs
• ✓ Four 4-watt high-intensity LED chips behind a Black Series panel
• ✓ Die-cast aluminum housing resists corrosion and manages heat
• ✓ Moisture Breather technology reduces moisture inside the cube
• ✓ IP67 waterproof rating for mud, snowmelt and pressure washing

What's Included

• One 3 in. LED cube spot light, Black Series
• DT pigtail connector and lead
• Mounting brackets
• Mounting hardware

Wiring harness and switch sold separately.

Fitting It Up

The housing measures 3.25 in. wide by 3.0 in. high with an overall depth of 3.0 in., so it clears most bar and bumper faces without a fight. Bolt diameter is 8mm and the 22 in. wiring lead gives you room to route to a harness connector.

Manufacturer Notes

Rated IP67 waterproof and covered by a 3-year warranty.

Why It Works

You get reach out of a housing small enough to mount almost anywhere, without cutting into a panel to do it. Low draw lets you run a pair off one circuit, and the sealed aluminum body handles the abuse that comes with rack, trailer and off-road duty.

Specifications

• Light Type: LED
• Light Wattage: 16 Watt
• Brightness: 1,440 Lumens
• Light Pattern: 8-degree spot beam
• Beam Type: Spot
• Amp Draw: 1.3 Amps
• LED Chips: 4 x 4-watt high intensity LED chips
• Size: 3 inch cube; overall depth 3.0 in.; housing 3.25 in. W x 3.0 in. H
• Material: Die-cast aluminum
• Panel Design: Black
• Series: Black Series
• Waterproof Rating: IP67
• Bolt Diameter: 8 mm
• Mounting: Universal surface mount (bumpers, roof racks, trailers, UTVs)
• Connector Type: DT pigtail, 22 inch wiring lead
• Sold As: Kit, single LED cube
• Kit Components: One LED cube light, DT pigtail, mounting brackets, hardware
• Wiring Harness: Harness/switch sold separately
• Warranty: 3 Year Warranty

If its flood-beam sibling is about lighting the space around you, this cube is about lighting the space ahead of you. Same footprint, opposite job, and most rigs eventually want both.
